Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Tension (N)		Crash loading (N/100mm)
Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Short term	Long term	Short term	Long term
2-30	9.8	102	≥1500	≥600	≥1000	≥300
32-60	10.7	117
62-72	11.3	143
74-84	12.7	173
86-96	12.7	173
98-120	14.5	211
122-144	16.0	230
146-216	16.7	262
218-300	19.0	302

PERFORMANCE

* Max attenuation : 0.35dB @ 1310nm and 0.21dB/Km @1550nm
* Fiber : G652D
* Installation : Aerial or duct
* Application : Apply to Long distance communication system, Local area network system
* Lifetime : above 30 years
* Operating temperature : -40℃~+70℃
* Permisson bent radius Static : 10 times O.D. Dynamic : 20 times O.D.
