| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation (+20℃） |
850nm | ≤3.0dB/km | ≤3.0dB/km | ||
| 1300nm | ≤1.0dB/km | ≤1.0dB/km | |||
| 1310nm | ≤0.36dB/km | ≤0.40dB/km | |||
| 1550nm | ≤0.22dB/km | ≤0.23dB/km | |||
| Bandwidth(Class A) | 850nm | ≥500MHZ·km | ≥500MHZ·km | ||
| 1300nm | ≥1000MHZ·km | ≥600MHZ·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelength |
≤1260nm | ≤1480nm | |||
| Cable Type | Fiber Count | Loose tube count T |
Filler count s |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/short term N |
Crush Resistance Long/short term N/100m |
Bending Radius Static/dynamic mm |
| GYTY53-2~6 | 2-6 | 1 | 4 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-8~12 | 8-12 | 2 | 3 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-14~18 | 14-18 | 3 | 2 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-20~24 | 20-24 | 4 | 1 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-26~30 | 26-30 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-32~36 | 32-36 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-38~48 | 38-48 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-50~60 | 50-60 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-62~72 | 62-72 | 6 | 0 | 13.2 | 200 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-74~84 | 74-84 | 7 | 1 | 15.0 | 240 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-86~96 | 86-96 | 8 | 0 | 15.0 | 240 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-98~108 | 98-108 | 9 | 1 | 16.0 | 280 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-110~120 | 110-120 | 10 | 0 | 16.0 | 280 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-122~132 | 122-132 | 11 | 1 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-130~144 | 134-144 | 12 | 0 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-146~216 | 134-144 | 18 | 0 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
