Product Structure |
|
Conductor |
Single or stranded bare copper or tinned copper wires comply with UL758&UL1581 and CSA C22.2 NO.210.05 standards |
Insulation |
Environmental PVC insulation, passed VW-1 flame retardant test |
Core Structure |
Layered structure |
Application Standards |
UL758,UL1581 ,CSA C22.2 No.210.2 |
Technical parameters |
|
Rated Voltage |
600V |
Rated Temperature |
105℃ |
Flammability test |
Passed UL VW-1, CSA FT1 flame retardant tests |
Application scenarios |
Suitable for electronic and electrical equipment internal connection lines |
Certification |
RoHS |
Conductor |
Insulation |
Shield |
Drain |
Braid |
Jacket |
MAX.COND. Resistance(Ω/km,20℃,DC) |
|||||
AWG |
Structure(No./mm) |
Outer Diameter(mm) |
Core number |
Insulation Thickness(mm) |
Outer Diameter(mm) |
Structure |
Structure(no/mm) |
Structure (mm) |
Jacket Thickness(mm) |
Outer Diameter(mm) |
|
26 |
7/0.16 |
0.48 |
2 |
0.23 |
1 |
Al-mylar |
7/0.16 |
0.12 |
0.76 |
3.5 |
150 |
3 |
1 |
Al-mylar |
0.12 |
3.7 |
|||||||
4 |
1 |
Al-mylar |
0.12 |
3.9 |
|||||||
5 |
1 |
Al-mylar |
0.12 |
4.2 |
|||||||
24 |
7/0.20 11/0.16 |
0.61 |
2 |
0.23 |
1.1 |
Al-mylar |
7/0.20 |
0.12 |
0.76 |
3.7 |
94.2 |
3 |
1.1 |
Al-mylar |
0.12 |
3.9 |
|||||||
4 |
1.1 |
Al-mylar |
0.12 |
4.2 |
|||||||
5 |
1.1 |
Al-mylar |
0.12 |
4.5 |
|||||||
22 |
17/0.16 |
0.76 |
2 |
0.23 |
1.3 |
Al-mylar |
17/0.16 |
0.12 |
0.76 |
4.1 |
59.4 |
3 |
1.3 |
Al-mylar |
0.12 |
4.3 |
|||||||
4 |
1.3 |
Al-mylar |
0.12 |
4.7 |
|||||||
5 |
1.3 |
Al-mylar |
0.12 |
5.0 |
|||||||
20 |
21/0.178 26/0.16 |
0.94 |
2 |
0.23 |
1.5 |
Al-mylar |
21/0.178 |
0.12 |
0.76 |
4.5 |
36.7 |
3 |
1.5 |
Al-mylar |
0.12 |
4.8 |
|||||||
4 |
1.5 |
Al-mylar |
0.12 |
5.2 |
|||||||
5 |
1.5 |
Al-mylar |
0.12 |
5.6 |
