Product Structure |
|
|
Conductor |
Stranded bare or tinned copper wires, conforming to IEC60228 category 5 |
|
Insulation |
Special PVC mixed material |
|
Jacket Material |
Special PVC mixed material |
|
Core Structure |
Layered structure |
|
Application Standards |
BS6500，VDE0250，BS6360，IEC60228，IEC60227-7 |
|
Technical parameters |
|
|
Rated Voltage |
600V |
|
Test Voltage |
3000V |
|
Rated Temperature |
70℃ |
|
Operating Temperature |
|
|
Minimum Bending Radius |
|
|
Flame Retardant |
Flame retardant and self-extinguishing in line with IEC60332-1-2 |
|
Application Scenario |
Suitable for dry or wet indoor fixed installation in industrial environment, also can be used for mobile installation with continuous reciprocating motion without forced traction such as drag chain |
|
Certification |
CE,RoHS |
|
Type |
Conductor |
Insulation |
Jacket |
||||
|
Conductor |
Insulation |
Thickness |
Outer Diameter |
Material |
Thickness |
Outer Diameter |
|
|
YY 2X0.5 |
16/0.19 |
Special PVC mixed material |
0.5 |
1.90 |
Special PVC mixed material |
0.60 |
5.28 |
|
YY 3X0.5 |
16/0.19 |
0.5 |
1.90 |
0.80 |
5.97 |
||
|
YY 4X0.5 |
16/0.19 |
0.5 |
1.90 |
0.80 |
6.46 |
||
|
YY 5X0.5 |
16/0.19 |
0.5 |
1.90 |
0.80 |
7.01 |
||
|
YY 2X0.75 |
24/0.19 |
0.6 |
2.30 |
0.80 |
6.48 |
||
|
YY 3X0.75 |
24/0.19 |
0.6 |
2.30 |
0.80 |
6.83 |
||
|
YY 4X0.75 |
24/0.19 |
0.6 |
2.30 |
0.80 |
7.43 |
||
|
YY 5X0.75 |
24/0.19 |
0.6 |
2.30 |
0.90 |
8.29 |
||
|
YY 2X1 |
32/0.19 |
0.6 |
2.50 |
0.80 |
6.88 |
||
|
YY 3X1 |
32/0.19 |
0.6 |
2.50 |
0.80 |
7.26 |
||
|
YY 4X1 |
32/0.19 |
0.6 |
2.50 |
0.90 |
8.11 |
||
|
YY 5X1 |
32/0.19 |
0.6 |
2.50 |
0.90 |
8.83 |
||
|
YY 2X1.5 |
30/0.245 |
0.73 |
3.00 |
0.80 |
7.88 |
||
|
YY 3X1.5 |
30/0.245 |
0.73 |
3.00 |
0.90 |
8.54 |
||
|
YY 4X1.5 |
30/0.245 |
0.73 |
3.00 |
1.00 |
9.52 |
||
|
YY 5X1.5 |
30/0.245 |
0.73 |
3.00 |
1.10 |
10.58 |
||
